NEW Vibration Cutting Control for Lathes

With the M800V/M80V Series, you can insert G-code commands into your existing program to activate Vibration Cutting Control, which vibrates the cutting tool in the cutting direction to break up chips into finer pieces.

M800V-M80V Series for Setup for Machining for Production maintenance for Machine tool builders for Machine tool users

NEW Vibration Cutting Control for Machining Centers

With the M800V/M80V Series, you can insert G-code commands into your existing program to activate Vibration Cutting Control, which vibrates the cutting tool in the cutting direction to break up chips into finer pieces.

M800V-M80V Series for Setup for Machining for Production maintenance for Machine tool builders for Machine tool users

Laser processing control

The introduction of laser processing functionality expands the areas of control.

M800V-M80V Series for Mechanical and Electrical design for Machine tool builders

Image input interface

â€œImage input interfaceâ€ enables flexible customization of NC screens and applications to differentiate machine tools, creating added value.

M800V-M80V Series for Mechanical and Electrical design for Machine tool builders

MELSEC development Tool(GX Works2)

ST language is supported in addition to the ladder language. This allows PLC programs to be created and edited efficiently using the syntax resembling that of conventional programming languages.

M800V-M80V Series for Mechanical and Electrical design for Machine tool builders

Motion control release(coordinate transformation)

Motion control release allows transformation of coordinates different from the NC's rectangular coordinate system, making it possible to control special mechanisms such as parallel link.

M800V-M80V Series for Mechanical and Electrical design for Machine tool builders

Multi-touch gestures

M800/M80 Series' usability has further evolved! Multi-touch gestures enables smarter operations.

M800V-M80V Series for Setup for Machine tool builders for Machine tool users

3D machining simulation

Machine interference and machining quality can be checked before machining, which reduces workpieces discarded because of trial cutting and defective machining.

M800V-M80V Series for Setup for Machine tool users

OMR-CC(Optimum machine response-contour control)

OMR-CC (Optimum machine response-contour control) smartly reduces cycle time while maintaining the current machining accuracy.

M800V-M80V Series for Machining for Machine tool builders for Machine tool users

Cutting load control

Cutting load control function automatically controls cutting load, leading to a longer tool life and shorter cycle time.

M800V-M80V Series for Machining for Machine tool builders for Machine tool users

Tool cutting point control

Tool cutting point control enables optimum machining without modifying the machining program even when the tool shape changes.

M800V-M80V Series for Setup for Machining for Machine tool users

Spline interpolation 2

Spline interpolation 2 function achieves high-quality fine surface by making adjacent machining paths globally smooth.

M800V-M80V Series for Machining for Machine tool builders for Machine tool users

Built-in Wireless LAN and peripheral software tool connection

Built-in Wireless LAN and peripheral software tool connection increase work efficiency.

M800V-M80V Series for Mechanical and Electrical design for Setup for Production maintenance for Machine tool builders for Machine tool users

Two-dimensional barcode engraving cycle

Two-dimensional barcode engraved directly on the workpiece allows automatic selection of programs and tools and helps to implement traceability easily.

M800V-M80V Series for Machining for Production maintenance for Machine tool users

Equipped with Remote Maintenance Gateway

The functionality of the remote service gateway unit required for remote service iQ Care Remote4U is built into the NC control unit, leading to less wiring and easier remote diagnostics.

M800V-M80V Series for Production maintenance for Machine tool builders for Machine tool users

Security feature for Windows display

Virus attacks can be prevented by prohibiting software not whitelisted (unauthorized) for the NC from being run. It addresses the security needs posed by the growth of the IoT.

M800V-M80V Series for Mechanical and Electrical design for Production maintenance for Machine tool users

Direct robot control

Guidance on the dedicated screen and special G codes allow easy programming and operation without requiring knowledge of robot language.

M800V-M80V Series for Mechanical and Electrical design for Setup for Machine tool builders for Machine tool users

Adjustment of high-accuracy parameters

The parameters for high-accuracy control can be adjusted through intuitive operation using three machining indexes (cycle time, accuracy, quality) displayed in the guidance.

M800V-M80V Series for Setup for Machining for Machine tool users

Videos

Videos of M800V/M80V series feature introduction
